Extend Map CustVendTrans

Scenario

New field MyNewField as NoYes on CustTrans and VendTrans

Simple solution

Obejcts

Create method parmMyNewField on CustVendTans, CustTrans and VendTrans using Table code extensions.

Usage

custVendTrans.parmMyNewField(NoYes::Yes) will work fine if the record hast been inserted.

Issue

If custVendTrans has not yet been inserted a call to custVendTrans.parmMyFlag(NoYes::Yes) will result in the errors
“Error executing code: CustTrans table does not have method ‘parmMyNewField’.“
or
“Error executing code: VendTrans table does not have method ‘parmMyNewField’.“

Full Solution

Extend the CustVendTransInterface class to properly handle mapped functions irrespective of the record being created or not.

Objects

Create class MyCustVendTransInterface following plugin design pattern, decorated with [… ExportInterfaceAttribute]
- Create sub-class MyCustTransCustVendTrans
  decorated with [… ExportMetadataAttribute(…CustTrans…), … ExportAttribute(…MyCustVendTransInterface…)]
- Create sub-class MyVendTransCustVendTrans
  decorated with [… ExportMetadataAttribute(…VendTrans…), … ExportAttribute(…MyCustVendTransInterface…)]

[Microsoft.Dynamics.AX.Platform.Extensibility.ExportInterfaceAttribute]
public abstract class MyCustVendTransInterface
{
    CustVendTransInterface custVendTransInterface;

    private void initializeCustVendTransInterface(CustVendTransInterface _custVendTransInterface)
    {
        custVendTransInterface = _custVendTransInterface;
    }

    public CustVendTrans parmCustVendTrans()
    {
        return custVendTransInterface.parmCustVendTrans();
    }

    protected void new()
    {
    }

    public static MyCustVendTransInterface createInstance(CustVendTransInterface _custVendTransInterface)
    {
        SysPluginMetadataCollection metadataCollection = new SysPluginMetadataCollection();

        metadataCollection.SetManagedValue(classStr(MyCustVendTransInterface), tableId2Name(_custVendTransInterface.parmCustVendTrans().tableId));
        MyCustVendTransInterface instance = SysPluginFactory::Instance(identifierStr(Dynamics.AX.Application), classStr(MyCustVendTransInterface), metadataCollection);

        instance.initializeCustVendTransInterface(_custVendTransInterface);

        return instance;
    }

    public NoYes parmMyNewField(NoYes _myNewField= NoYes::No)
    {
        return _myNewField;
    }
}

[System.ComponentModel.Composition.ExportMetadataAttribute(classStr(MyCustVendTransInterface), tableStr(CustTrans))
    ,System.ComponentModel.Composition.ExportAttribute('Dynamics.AX.Application.MyCustVendTransInterface')]
public class MyCustTransCustVendTrans extends MyCustVendTransInterface
{
    private CustTrans parmCustTrans()
    {
        return this.parmCustVendTrans();
    }

    public NoYes parmMyNewField(NoYes _myNewField = this.parmCustTrans().MyNewField)
    {
        CustTrans   custTrans = this.parmCustTrans();
        custTrans.MyNewField = _myNewField;
        return custTrans.MyNewField;
    }
}

[System.ComponentModel.Composition.ExportMetadataAttribute(classStr(MyCustVendTransInterface), tableStr(VendTrans))
    ,System.ComponentModel.Composition.ExportAttribute('Dynamics.AX.Application.MyCustVendTransInterface')]
public class MyVendTransCustVendTrans extends MyCustVendTransInterface
{
    private VendTrans parmVendTrans()
    {
        return this.parmCustVendTrans();
    }

    public NoYes parmMyNewField(NoYes _myNewField = this.parmVendTrans().MyNewField)
    {
        VendTrans   vendTrans = this.parmVendTrans();
        vendTrans.MyNewField = _myNewField;
        return vendTrans.MyNewField;
    }
}

Optional: create extenstion class CustVendTransInterface_My_Extension
to provide simple access to the newly created class MyCustVendTransInterface

[ExtensionOf(classStr(CustVendTransInterface))]
final class MyCustVendTransInterfaceCls_Extension
{
    private MyCustVendTransInterface MyCustVendTransInterface;

    public MyCustVendTransInterface MyCustVendTransInterface()
    {
        if (!MyCustVendTransInterface)
        {
            MyCustVendTransInterface = MyCustVendTransInterface::createInstance(this);
        }

        return MyCustVendTransInterface;
    }
}

Usage

//if extension CustVendTransInterface_My_Extension implemented
MyCustVendTransInterface myCustVendTransInterface = CustVendTransInterface::createInstance(custVendTrans).myCustVendTransInterface()
//if extension CustVendTransInterface_My_Extension not implemented
MyCustVendTransInterface myCustVendTransInterface = MyCustVendTransInterface::createInstance(CustVendTransInterface::createInstance(custVendTrans))
//access field
myCustVendTransInterface.parmMyNewField(NoYes::Yes);

Final notes

Microsoft documents the extension of maps here:
Extend table maps that are used as interfaces
However the example SalesPurchTable they are using has a special attribute class to decorate the methods (SalesPurchTableInterfaceFactoryAttribute. The example here is both more generic and simpler.

9 May 2023

Electronic Reporting on DEVBox

If you do not have a connection to LCS on your DEVBox you can still access the new Microsoft definitions by doing the following:

Download the definitions from LCS

https://lcs.dynamics.com/V2/SharedAssetLibrary

“DOWNLOAD ALL” in LCS

Extract in DEVBox

C:\Temp\SolutionRepository

Extract LCS ZipFile to C:\Temp\SolutionRepository

Add File System Repository

https://usnconeboxax1aos.cloud.onebox.dynamics.com/?cmp=USMF&mi=ERWorkspace

Edit the Microsoft Repositories

Add a “File system” repository. NOTE: This requires the debugger – see next step.

Debugger required

Set breakpoint in ERSolutionImportRepository::getTypes() and use the debugger to add the ERSolutionFileSystemRepository type.

Import local definitions

Open the newly added file system repository

Import the desired definitions – or import all if you like.

25 March 2020

Find Datatypes (updated)

Update of my old script to D365

class FindEDT
{
    public static void main(Args _args)
    {
        #AOT
        Dialog              dialog = new Dialog('Find EDT');
        str                 searchString;
        DialogField         dialogField = dialog.addField(extendedTypeStr(MCRSearchText), 'Search string');
        boolean             stopAfterFound;
        ;
        if(dialog.run())
        {
            searchString = dialogField.value();
            if(!strScan(searchString, "*", 1, 999)) //no "*"
            {
                searchString = "*" + searchString + "*";
            }
            else if(strKeep(searchString,"*") == "*" && subStr(searchString,strLen(searchString),1)=="*") //just one final "*": beginns with
            {
                stopAfterFound = true;
            }
            info(strfmt("Find %1",searchString));
            if(searchString)
            {
                setPrefix('Extended Data Types');
                FindEDT::searchNodes(#ExtendedDataTypesPath, searchString, stopAfterFound);
                setPrefix('Base Enums');
                FindEDT::searchNodes(#BaseEnumsPath, searchString, stopAfterFound);
            }
        }
    }
    static void searchNodes(str _basePath, str _searchString, boolean _firstonly)
    {
        #AOT
        TreeNode            treeNode;
        TreeNodeIterator    treeNodeIterator;
        SysDictType         sysDictType;
        SysDictEnum         sysDictEnum;
        Boolean             found;
        ;
        treeNode = TreeNode::findNode(_basePath);
        treeNodeIterator = treenode.AOTiterator();
        treeNode = treeNode.AOTfirstChild();
        treeNode = treeNodeIterator.next();
        while(treeNode)
        {
            if(treeNode.treeNodeName() like "*" + _searchString + "*")
            {
                if(_basePath == #ExtendedDataTypesPath)
                {
                    sysDictType = sysDictType::newTreeNode(treeNode);
                }
                if(sysDictType)
                {
                    if (sysDictType.extend() && sysDictType.enumId())
                    {
                        info(strfmt("%1 (%2 - %3 -> %4)",treeNode.treeNodeName(), sysDictType.baseType()
                                    , extendedTypeId2name(sysDictType.extend()), enumId2Name(sysDictType.enumId()) ));

                    }
                    if(sysDictType.extend())
                    {
                        info(strfmt("%1 (%2 - %3)",treeNode.treeNodeName(), sysDictType.baseType()
                                    , extendedTypeId2name(sysDictType.extend()) ));

                    }
                    else if (sysDictType.enumId())
                    {
                        info(strfmt("%1 (%2 - %3)",treeNode.treeNodeName(), sysDictType.baseType()
                                    , enumId2Name(sysDictType.enumId()) ));

                    }
                    else
                    {
                        info(strfmt("%1 (%2)",treeNode.treeNodeName(), sysDictType.baseType()));
                    }
                }
                else
                {
                    info(strfmt("%1",treeNode.treeNodeName()));
                }
                found = true;
            }
            else if(_firstOnly && found)
            {
                return;
            }
            treeNode = treeNodeIterator.next();
        }
    }
}

Run with the following link:

https://usnconeboxax1aos.cloud.onebox.dynamics.com/?cmp=usmf&mi=SysClassRunner&cls=FindEDT

29 February 2020

Deep links available in every form

Ievgen Miroshnikov gave me the idea and Microsoft also has some information here.

The following extends the standard button available in every Dynamics 365 for Finance and Operations form to provide the deep link to the currently select record of the primary form data source.

Copy the link and share it. The recipient will jump directly to the currently selected record.

(I wonder why Microsoft doesn’t provide this in standard D365FO – this is actually what you would expect from the button.)

using Microsoft.Dynamics.AX.Framework.Utilities;
using Microsoft.Dynamics.@Client.ServerForm.Contexts;

/// &lt;summary&gt;
/// The class &lt;c&gt;URLUtility_Extension&lt;/c&gt; contains extension methods for the &lt;c&gt;URLUtility&lt;/c&gt; class.
/// &lt;/summary&gt;
[ExtensionOf(classStr(URLUtility))]
public static class URLUtility_Extension
{
public static str generateRecordUrl(str _menuItemName, MenuItemType _menuItemType, DataSourceName _dataSourceName, Map _indexFieldValuesMap, DataAreaId _dataAreaId = curExt())
{
System.Uri host                     = SessionContext::Get_Current().Get_RequestUrl();
UrlHelper.UrlGenerator generator    = new UrlHelper.UrlGenerator();
generator.MenuItemName              = _menuItemName;
generator.MenuItemType              = _menuItemType;
generator.HostUrl                   = host.GetLeftPart(System.UriPartial::Path);
generator.Company                   = _dataAreaId;
generator.EncryptRequestQuery       = true;

if (_dataSourceName &amp;&amp; _indexFieldValuesMap)
{
MapEnumerator mapEnumerator = _indexFieldValuesMap.getEnumerator();

var requestQueryParameterCollection = generator.RequestQueryParameterCollection;

while (mapEnumerator.moveNext())
{
requestQueryParameterCollection.UpdateOrAddEntry(_dataSourceName, mapEnumerator.currentKey(), mapEnumerator.currentValue());
}
}

return generator.GenerateFullUrl().AbsoluteUri;
}

public static str generateRecordUrlFromDataSource(FormDataSource _formDataSource)
{
FormRun         formRun         = _formDataSource.formRun();
str             menuItemName    = formRun.args().menuItemName();
MenuItemType    menuItemType    = formRun.args().menuItemType();
DataSourceName  dataSourceName  = _formDataSource.name();

TableId   tableId   = _formDataSource.table();
DictTable dictTable = new DictTable(tableId);
DictIndex dictIndex = new DictIndex(tableId, dictTable.primaryIndex());

int     fieldCount          = dictIndex.numberOfFields();
Map     indexFieldValuesMap = new Map(Types::String, Types::String);
Common  record              = _formDataSource.cursor();
FieldId primaryKeyFieldId;

for (int fieldIndex = 1; fieldIndex &lt;= fieldCount; fieldIndex++)
{
primaryKeyFieldId = dictIndex.field(fieldIndex);

indexFieldValuesMap.insert(fieldId2Name(tableId, primaryKeyFieldId), any2Str(record.(primaryKeyFieldId)));
}

return URLUtility::generateRecordUrl(menuItemName, menuItemType, dataSourceName, indexFieldValuesMap, record.DataAreaId);
}

public static str generateUrl(FormRun formRun)
{
str url = next generateUrl(formRun);

if (formRun &amp;&amp; formRun.dataSource(1) &amp;&amp; formRun.dataSource(1).cursor())
{
url = URLUtility::generateRecordUrlFromDataSource(formRun.dataSource(1));
}
return url;
}
}

2 November 2017

Minimal Setup for new Workflow
Sumit created nice overview of workflow-implementations in AX:

Developing a new Workflow

The section below describes briefly, the process of developing a new workflow.

Overview

To develop a new workflow, following artifacts or objects need to be created / modified:
- Workflow Categories
- Workflow Templates
- Workflow Query (Document)
- Workflow Approvals and Tasks (Tasks are optional)
- Enabling the workflows on the form
- Workflow submission classes
Let us go through each of these artifacts one by one:

Create Workflow Categories

A workflow category defines the module in which the workflow will be available. Modules are defined by the SysModule enum. You will be doing following here:
- Create a new category in workflow categories node (AOT>>Workflow>>Workflow Categories)
- Specify the name and module to which it belongs
Create Workflow Templates (AX 2012: Workflow Types)

A workflow template brings all the different elements of the workflow together. Workflow configurations are created based on a template, and many configurations can be based on the same template. The template defines which actions are allowed and which are required.

You will be doing following here:
- Create a new template in the workflow templates node (AOT>>Workflow>>Workflow Templates) (AX 2012: AOT>>Workflow>>Workflow Types)
- Specify a name and category to which it belongs
Next we create a work flow document.

Create Workflow Document

A query defines what tables are used to determine that a workflow can be initiated. Here you will do the following
- Create a new query (AOT>>Queries)
- Specify a name and Add required tables to the data source.
- Create a new class extending from WorkFlowDocument class (AOT>>Classes)
- Override the method getQueryName and return the name of newly created query
- Save the class
- Once query and its supporting class is created, attach this to Workflow template (Specify it under the Document property of template; AX 2012: type)
Next step is to attach Approvals and / or Tasks

Create Workflow Approvals (or Tasks):

An approval route may contain a number of outcomes. It may be approved, rejected, returned or a change may be requested (For task it will be complete, reject or request change). The Workflow Approval element determines which of these outcomes is allowed and what happens in the event of each outcome. Each outcome can trigger specific code by specifying a menu item for each item. Do the following to create an approval
- Create a new approval object in the Approvals node. (AOT>>Workflow>>Approvals)
- Specify a unique name for the approval
- Specify the Document (The class created for query) in the Document property
- Specify ParticipantProvider. Normally you specify WorkflowUserGroupParticipantProvider, but you can create your own participant provider. (Missing in AX 2012)
- Specify DueDateProvider. Normally you specify WorkflowWorkCalendarDueDateProvider, but you can create your own due date provider. (Missing in AX 2012)
- Specify HierarchyProvider. Normally you specify WorkflowLimitHierarchyProvider, but you can create your own hierarchy provider. (Missing in AX 2012)
- Set the DocumentMenuItem to form menu item where you want the workflow to appear (Example sales order etc.)
- Approval Outcomes:
  - Use a standard class that acts as an engine for all approval outcomes
  - You are not required to do anything but set the workflow to applicable outcomes, therefore call the same class from different menu items. The menu items simply allow you to use two different labels. In more complex workflows it may be necessary to override or copy and modify this class rather than use it directly. Example: If you have to set an outcome for Approved do the following:

    Create a new Action type menu item and specify a name to it

    Set ObjectType property to Class and Object property to WorkflowWorkItemActionManager

    Now get to Workflow>>Approvals>>Approval_you_created>>Outcomes>>Approve node and specify ActionMenuItem as new menuitem created before.

    Repeat Step 2 for all the outcomes you need
  - If you do not need an outcome you can simply disable it by changing Enabled property to No
- Once completed, drag and drop this approval (or task) into the previously created workflow template (AX 2012: Worfklow Type)
Enable workflow on a form

Now that the workflow template is defined, you can specify which forms will use this template. Do the following:
- Add a WorkflowState field (More can be added by CreatedBy, Time, Status etc.) to the required table
- In the desired form, go to the design node properties and set property WorkFlowEnabled to “Yes”, set the WorkFlowDataSource (the table of the previous step) and (AX 2012 only) set the WorkflowType as defined above.
- If you want, you can override the method canSubmitToWorkflow on the form and specify conditions when user can submit the record to workflow
After enabling the workflow on class, create a class to submit the records to workflow

Create a Submit to Workflow class

To submit a document to workflow, call standard code to prompt the user for a comment and to process the submission. (Look at PurchReqWorkflow class for an example)
- After creating the submit to workflow class, create a corresponding action menu item
- Now traverse to the workflow template (AX 2012: Worfklow Type) and specify this submit to workflow class menu item on the SubmitToWorkFlowMenuItem property
- Once this is done you can then configure the workflow and test it. (You can refer the Workflows – Installation and Configuration document that I sent earlier for configuring the workflows)
This will give you a broad idea as to what needs to be done for creating a workflow.

Compile

In AX 2012 it is required to update CIL before the Workflow can be configured.

(updated for AX 2012 on 07/07/2014)
14 March 2016
Product configurator data structure

Even though AX 2012 uses the Microsoft Solver Foundation which is not directly accessible to a developer, all data is stored within AX and can be worked with at will. See the follow overview of the data structure:

Note that most of the data is global, just the PCTemplateComponent table has company specific entries; the table is used for templates – as the name suggests – but also for the item references eg. for Configurator BOM lines.

21 January 2016

Add document to record

Simple code snippet to add a document attachment to a record:

static void addDoc( Common common, DocuTypeId docuTypeId, FileName fileName)
{
    DocuRef docuRef;
    DocuValue docuValue;
    if(common && docuTypeId)
    {
        ttsBegin;
        docuRef.clear();
        docuRef.initValue();
        docuRef.TypeId = docuTypeId;
        docuRef.Name = filename;
        docuRef.RefRecId = common.RecId;
        docuRef.RefTableId = common.TableId;
        docuRef.RefCompanyId = curext();
        docuValue.initFromDocuRef(docuRef);
        docuValue.insert();
        docuRef.ValueRecId = docuValue.RecId;
        docuRef.insert();
        ttsCommit;
        if(filename)
        {
            //after ttsCommit to enable catching of file system errors
            DocuValue::writeDocuValue(docuRef,filename);
        }
    }
}

10 November 2015

Edit System Fields

Simple example for creating a record with systems fields set by code:

protected static server CaseLog createCaseLog(RefRecId _caseDatail, CreatedBy _createdBy, CreatedDateTime _createdDateTime)
{
    CaseLog caseLog;
    if(_createdBy &amp;&amp; _caseDatail)
    {
        caseLog.initValue();
        caseLog.CaseRecId = _caseDatail;
        new OverwriteSystemFieldsPermission().assert();
        caseLog.overwriteSystemfields(true);
        caseLog.(fieldNum(CaseLog,CreatedBy)) = _createdBy;
        caseLog.(fieldNum(CaseLog,CreatedDateTime)) = _createdDateTime;
        caseLog.doInsert();
        caseLog.overwriteSystemfields(false);
        CodeAccessPermission::revertAssert();
    }
    return caseLog;
}

9 November 2015

Show configuration on hand

The constraint based configuration is saved in relation to the configuration-number (InventDim.ConfigId), however all you see in the On-Hand form is the number.

If you want to see the full configuration that was entered by the user, you can add a simple button to the On-hand form (InventOnhandItem) and override the clicked() method with the following code:

void clicked()
{
    PCExecuteVariantConfiguration executeVariantConfiguration;
    ProdTable                     tmpProdTable;

    tmpProdTable.InventDimId = InventDim::findOrCreate(inventDim).InventDimId;
    tmpProdTable.ItemId      = InventSum.ItemId;

    if(PCRuntimeLibrary::isConstraintBasedConfigurable(InventSum.ItemId))
    {
        executeVariantConfiguration = PCExecuteVariantConfiguration::execute(tmpProdTable, InventSum.ItemId, inventDim.ConfigId);
    }
}

Result:

Open configuration from the on-hand form

11 August 2015

Showing hidden fields in the table browser

Starting off with this blog, I had my own ideas how to add the hidden fields to the table browser with a significantly lower development footprint: Private Project_Table Browser_2012.xpo

One hidden field:

Multiple hidden fields:

9 March 2015

Category: Development

Scenario

Simple solution

Obejcts

Usage

Issue

Full Solution

Objects

Usage

Final notes

Download the definitions from LCS

Extract in DEVBox

Add File System Repository

Debugger required

Import local definitions

Overview

Create Workflow Categories

Create Workflow Templates (AX 2012: Workflow Types)

Create Workflow Document

Create Workflow Approvals (or Tasks):

Enable workflow on a form

Create a Submit to Workflow class

Compile
